1.1  Product Name:  All-in-one type cyclone , air volume range： 500-6000CMH

1.2  A cyclone dust collector is a device that rotates a dusty airflow, uses centrifugal force to separate dust particles from the airflow, and captures them on the walls of the dust collector.

1.3 Then, with the help of gravity, dust particles fall into the ash hopper.

1.4 The advantage is that the structure is simple, no filtering materials are required, and the comprehensive cost of investment and use is saved.

1.5 Each component of a cyclone dust collector has a certain size ratio, and any change in the proportion relationship will affect the efficiency and pressure loss of the cyclone dust collector.

1.6 The diameter of the dust collector, the size of the inlet, and the diameter of the exhaust pipe are the main factors that affect the dust removal efficiency.

1.7 Tangential centrifugal force has a high dust removal efficiency for large particles and high-density dust.

1.8 Carbon steel material or stainless steel such as 304 and 316L can be selected, and wear-resistant ceramic or PTFE plastic anti-corrosion lining can be added to the inner wall.

1.9 Design service: Based on the size of your on-site space, design product drawings for free, and provide installation guidance and training services.

1.10 International transportation: Our product dimensions meet the requirements of container transportation, making it easy to transport to various parts of the world.
