1.1. This cartridge dust collection system is designed for robotic welding booths and fixed robotic welding cells where welding fumes are generated within a relatively defined working area.

1.2. It is suitable for collecting welding fumes and airborne particulate generated by one or multiple robotic welding stations operating in an industrial production area.

1.3. The robotic welding area can be enclosed or partially enclosed to help contain welding fumes and improve capture efficiency before the fumes spread into the surrounding workshop.

1.4. Fixed extraction openings or hoods can be arranged above the welding booth, where rising welding fumes can be captured and transferred to the dust collector through the extraction duct.

1.5. Multiple robotic welding booths can be arranged as independent production cells and connected to a centralized extraction system according to the production layout and required airflow.

1.6. Robotic welding can generate sparks and hot particles. Depending on the welding process, material and operating conditions, suitable spark arresting or pre-separation measures may be considered upstream of the cartridge dust collector.

1.7. The welding booth helps create a controlled extraction area. Since welding fumes generally rise due to thermal effects, overhead extraction can be used to collect fumes from the upper part of the booth.

1.8. Dry cartridge filtration is generally suitable for dry welding fumes and particulate. If significant oil, moisture or other special contaminants are present, the application conditions should be evaluated before selecting the filtration method.

1.9. Equipment drawings and interface information can be provided according to the selected dust collector configuration to support integration with the customer's welding booth and extraction system.

1.10. Modular equipment configurations can be provided for overseas projects to facilitate international transportation and on-site installation.
