1. Also known as an acid mist wet scrubber, it is designed for purification of corrosive industrial exhaust gases.
2. Mainly used for acid mist, alkaline fumes, lead-containing process fumes and other corrosive gas treatment applications.
3. Recirculating liquid operation helps reduce water consumption, with chemical dosing available according to the treatment process.
4. PP, PVC and other corrosion-resistant materials can be selected according to gas composition, temperature and operating conditions.
5. Designed for continuous industrial operation with stable airflow and convenient maintenance.
6. Additional treatment stages, including activated carbon filtration, can be configured when required by the application and target emission conditions.
Corrosion-resistant PP, PVC or other suitable materials can be selected according to gas composition, temperature and operating conditions.
Designed for industrial acid mist, alkaline fumes and other compatible corrosive exhaust gas purification applications.
Recirculating scrubbing liquid helps reduce water consumption, while chemical dosing can be configured according to the treatment process.
PLC touch-screen control, variable-frequency control and remote monitoring can be configured according to project requirements.
Compact modular construction is suitable for container transportation and convenient on-site assembly.
Plastic Sheet
Plastic Packing
Pall Ring Packing
Corrosion Resistant Liquid Filter
Acid and Alkali Resistant Pump
Automatic Chemical Dosing Device
Compact equipment structure helps reduce the required installation footprint.
Recirculating scrubbing liquid helps reduce fresh-water consumption during operation.
Corrosion-resistant construction materials can be selected according to the exhaust gas composition and process conditions.
Simple equipment structure supports convenient inspection, operation and routine maintenance.
Model selection should be based on airflow, gas composition, concentration, temperature and required treatment conditions.
Suitable for acid mist, alkaline fumes and other corrosive industrial exhaust gas purification applications.
OEM/private-label and customized manufacturing are available according to project requirements.
| Item No. | Model | Air Volume | Fan Model | Power | Total Pressure | T |
| m³/h | No. | kW | Pa | |||
| 1 | SST-650 | 1500 | F4-72-3.6A | 1.1 | 300 | 0 |
| 2 | SST-800 | 3000 | F4-72-4.5A | 1.1 | 350 | 0 |
| 3 | SST-1000 | 5000 | F4-72-5A | 2.2 | 400 | 0 |
| 4 | SST-1200 | 7500 | F4-72-6C | 4 | 700 | 0 |
| 5 | SST-1400 | 10000 | F4-72-6C | 4 | 900 | 0 |
| 6 | SST-1650 | 15000 | F4-72-7C | 4 | 900 | 0 |
| 7 | SST-2000 | 20000 | F4-72-8C | 7.5 | 900 | 0 |
| 8 | SST-2400 | 25000 | F4-72-10C | 15 | 900 | 0 |
Plastic Sheet
Plastic Welding Fabrication
Plastic Pipe Fittings
Plastic Equipment Fabrication
Equipment Delivery
Installation and Hoisting
Acid Mist Wet Scrubber
Installation and Hoisting
Electrolyzer Exhaust Treatment
Lead Acid Battery Plate Line
Lead Acid Battery Plate Line
Lead Acid Battery Forming Line
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Application Case
Install the wet scrubber according to the confirmed equipment layout, airflow direction, duct connections, drainage arrangement and site conditions. Connection dimensions and installation requirements should be confirmed before shipment.
Remote technical guidance can be provided for equipment installation and commissioning when required. Overall ducting/system design and local compliance remain subject to project-specific engineering.
