explosion-proof dust collector-Vertical filter cartridge type

Explosion-proof dust collector-Vertical filter cartridge type

1. Ordinary dust collectors are equipped with standard explosion-proof devices and combined to form an explosion-proof dust removal system.

2. The filter cartridge is made of flame-retardant and anti-static materials, and metal wires are installed for grounding to eliminate static electricity.

3. The fan adopts explosion-proof motor, with explosion-proof throat or aluminum impeller.

4. Pulse valves adopt coil explosion-proof or rubber proof types.

5. Modular manufacturing, modular assembly, and overall spray molding are used to meet the size of containers and can be shipped by sea to various parts of the world.

inquiry

Vertical Filter Cartridge Explosion-proof Dust Collector

Vertical Filter Cartridge Explosion-proof Dust Collector

1.1 Ordinary dust collectors are equipped with standard explosion-proof devices and combined to form an explosion-proof dust removal system.

1.2  The filter cartridge is made of flame-retardant and anti-static materials, and metal wires are installed for grounding to eliminate static electricity.

1.3 The fan adopts explosion-proof motor, with explosion-proof throat or aluminum impeller.

1.4 Pulse valves adopt coil explosion-proof or rubber proof types.

1.5 Install explosion-proof discs or flameless explosion-proof devices on the box.

Vertical Filter Cartridge Explosion-proof Dust Collector


1.6 The electrical control cabinet and pulse controller are equipped with explosion-proof cabinets.

1.7 Install a one-way explosion-proof valve on the main pipeline at the inlet of the dust collector.

1.8 Install dry powder fire extinguishers or fire water extinguishing systems.

1.9 Install Mars detection, temperature detection, and pressure difference detection instruments for online monitoring, and issue shutdown alarms if abnormalities are detected.

1.10 Design Services: Based on the size of your on-site space, design product drawings for free, and provide installation guidance and training services.


Multiple Forms Of Accessory Combinations

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_34.jpg

    Circular bursting disc

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_36.jpg

    Rectangular bursting disc

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_38.jpg

    Flameless explosion-proof device

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_40.jpg

    Explosion proof electrical cabinet

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_42.jpg

    Explosion proof pulse controller

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_50.jpg

    Explosion proof pulse valve

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_52.jpg

    Explosion-Proof Motor

  • resource/images/03ffdf8a94484f159fad1a56b4d23234_54.jpg

    Unidirectional explosion-proof valve
