1.1 The Venturi wet scrubber is equipped with a Venturi nozzle section at the inlet of the scrubber tower to enhance gas-liquid contact. A demister is installed inside the tower for droplet separation, and sludge collection devices can be configured for settled residues. Airflow capacity: 3000-100000 CMH.

1.2 A high-pressure water pump atomizes the scrubbing liquid in the Venturi section, creating intensive gas-liquid mixing for capturing particulate matter and gaseous contaminants.

1.3 After the scrubbing process, the gas enters the demister section where water droplets are separated before the treated air is discharged.

1.4 The Venturi section provides high-speed inertial contact between gas and liquid droplets, improving mass transfer and pollutant removal efficiency.

1.5 Water or chemical scrubbing solutions can be selected according to the characteristics of target gases and treatment requirements.

1.6 Chemical scrubbing solutions can be used for specific gas treatment applications, such as acid gas absorption, according to process requirements.

1.7 Compared with traditional packed tower scrubbers, Venturi scrubbers can reduce the need for packing media and are suitable for applications requiring efficient gas-liquid contact.

1.8 Optional instruments can be provided to monitor scrubbing liquid conditions, and chemical dosing systems can be configured according to application requirements.

1.9 OEM customization support is available according to installation space, airflow requirements and process conditions.

1.10 The modular design allows convenient transportation and installation for international projects.
