EHI Oblique All-in-one Machine
EHI Compact Cartridge Dust Collector with 350 x 660 mm Filter Cartridges

EHI Compact Cartridge Dust Collector with 350 x 660 mm Filter Cartridges

1. The EHI is a compact all-in-one cartridge dust collector designed for use with 350 x 660 mm filter cartridges and side insertion cartridge replacement.

2. The inclined cartridge arrangement provides a compact structure and allows cartridge maintenance from the side without requiring additional service space above the collector.

3. The integrated design combines the dust collector, fan and electrical control system in one unit, simplifying installation and reducing the required floor space.

4. Filter cartridges are cleaned by pulse jet compressed air to remove accumulated dust from the filter surface and maintain stable operating resistance.

5. The EHI is suitable for collecting dry industrial dust without oil or excessive moisture, including applications such as laser cutting, 3D printing and other low to moderate dust concentration processes.

EHI Compact Cartridge Dust Collector with 350 x 660 mm Filter Cartridges

EHI Compact Cartridge Dust Collector with 350 x 660 mm Filter Cartridges

1.1 Product Name: EHI Compact Cartridge Dust Collector with 350 x 660 mm Filter Cartridges.

1.2 Cartridge Arrangement: The filter cartridges use a side insertion and inclined installation structure for convenient maintenance and replacement.

1.3 Maintenance Design: Cartridge replacement is performed from the side, reducing the need for additional service space above the collector and making the unit suitable for indoor installations.

1.4 Filter Cartridge Size: The EHI series is designed for 350 x 660 mm filter cartridges.

1.5 Cartridge Construction: The cartridge end caps and internal support structure are designed for reliable pulse jet cleaning and stable operation under repeated compressed air cleaning cycles.

EHI All in One Cartridge Dust Collector

1.6 Integrated Design: The dust collector, fan and electrical control system are integrated into one compact unit to simplify installation and commissioning.

1.7 Equipment Materials: Carbon steel with painted or powder coated surface treatment is commonly used, while stainless steel construction can be selected according to project requirements.

1.8 Applications: The compact structure is suitable for dry dust applications with low to moderate dust concentrations, including laser cutting, 3D printing and other localized industrial dust collection processes.

1.9 Customization: Equipment dimensions, inlet and outlet arrangement, fan configuration and electrical control can be customized according to airflow and installation requirements.

1.10 International Transportation: The compact modular structure is designed for convenient packing, container loading and overseas transportation.

Application Cases

  • EHI 2 Cartridge Dust Collector

    EHI-2 Type

  • EHI 3 Cartridge Dust Collector

    EHI-3 Type

  • EHI 4 Cartridge Dust Collector

    EHI-4 Type

  • EHI 4N Cartridge Dust Collector

    EHI-4N Type

  • EHI 6 Cartridge Dust Collector

    EHI-6 Type

  • EHI 6N Cartridge Dust Collector

    EHI-6N Type

Multiple Accessory Configurations

  • Dust Collection Drawer

    Short Leg Dust Hopper
    Drawer Type Dust Box

  • Pulse Jet Air Tank

    Pulse Jet Air Tank
    Compressed Air Storage

  • Pulse Jet Valve

    Pulse Valve
    Compressed Air Cleaning

  • 350 x 660 mm Filter Cartridge

    Filter Cartridge
    Size 350 x 660 mm

  • Filter Cartridge Support Structure

    Cartridge Support Structure
    Side Insertion Design

  • Dust Collector Fan

    Fan
    Air Extraction

Model Selection Table
Selection Table for EHI Cartridge Dust Collector

EHI Cartridge Dust Collector Model Selection Table

Drawing Examples
Selection Size for EHI Cartridge Dust Collector
