1.1 The EHDLMC-Car is a compact integrated flat bag dust collector designed for container installation and mobile dust collection applications. Airflow capacity: 1000-6000 CMH.

1.2 The all-in-one design integrates flat bag filtration, fan system and electrical control components into one compact unit.

1.3 PTFE membrane filter bags can be selected according to application requirements to provide efficient filtration performance for fine dust applications.

1.4 Pulse jet cleaning uses compressed air through electromagnetic pulse valves to remove dust accumulated on the surface of filter bags.

1.5 The equipment consists of compact independent modules and can be configured with different flat bag combinations according to project requirements.

1.6 The modular design allows convenient transportation and installation inside containers or compact project spaces.

1.7 The flower board and bag cage are manufactured by precision forming processes. Carbon steel or stainless steel materials can be selected.

1.8 The side insertion flat bag design does not require top maintenance space and allows convenient filter replacement.

1.9 OEM customization support is available according to airflow requirements, dust characteristics and installation conditions.

1.10 The compact structure meets international container transportation requirements for overseas projects.
