1.1 The EHHVF-XL cyclone flow flat bag dust collector combines swirling airflow pre-separation with flat bag filtration technology, providing high airflow capacity and high negative pressure performance.

1.2 The cylindrical housing design provides strong pressure resistance. The double-layer conical hopper with central air inlet creates a cyclone flow effect before filtration.

1.3 The swirling airflow helps reduce direct dust impact on filter bags and improves filtration stability under high concentration dust conditions.

1.4 The flat bag filtration structure provides a large filtration area with a compact footprint compared with conventional round bag dust collectors.

1.5 The envelope-shaped flat filter bag design improves cleaning performance and supports effective pulse jet dust removal.

1.6 The flat filter bag edge adopts seamless three-dimensional manufacturing technology to improve sealing performance.

1.7 The flat bag is fixed tightly with the supporting frame to ensure reliable installation and stable operation.

1.8 Carbon steel or stainless steel materials can be selected according to different application requirements.

1.9 Intelligent control options include PLC control, touch screen display, differential pressure monitoring and compressed air monitoring.

1.10 Explosion-proof configurations can be selected according to dust characteristics and project requirements.
