1.1 The multi tube combined cyclone dust collector consists of multiple cyclone tubes working together to separate dust particles from airflow through centrifugal force. Airflow capacity: 20000-100000 CMH.

1.2 The cyclone dust collector rotates dusty airflow and uses centrifugal force to separate dust particles from the air stream, collecting separated dust into the hopper.

1.3 Multiple cyclone tubes increase processing capacity while maintaining efficient separation performance for large particles and high density dust.

1.4 The cyclone system does not require filter media, providing simple structure, low maintenance requirements and reliable operation.

1.5 The design parameters of cyclone tubes, including diameter, inlet size and outlet diameter, affect separation efficiency and pressure loss.

1.6 The cyclone diameter, inlet dimensions and exhaust outlet size are important factors affecting dust separation efficiency.

1.7 Tangential centrifugal force provides effective separation for large particles and high density dust materials.

1.8 Carbon steel or stainless steel materials can be selected according to application requirements. Wear-resistant lining options are available for abrasive dust applications.

1.9 OEM customization support is available according to airflow requirements, dust characteristics and installation conditions.

1.10 The modular design allows convenient transportation and installation for international projects.
